APEX 1516 One Axis CNC Wood Turning Lathe for Baseball Bat Legs

Short Description:

Main feature of cnc wood lathe
1. Whole machine is welded with seamless steel structure, which is high temperature annealing and vibrating stress relief,
machine weight up to 1500kgs to make sure the lathe body stabilized and never deformed.
2. Special used for wood turning and wooden cylinder engraving, for table legs,stair railing (banisters), etc.
3.Adopting advanced handheld DSP system with USB port which is easy for operating even without a computer
4. Adopt Germany ball screw and Taiwan HIWIN helical square guide rail with high precision and longevity.
5. Compatible with several CAD/CAM design software, e.g. type3, artcam, etc.
6. Rotating speed can be adjusted by inverter also you can see speed on control cabinet panel
7. One time tool setting to finish the whole work piece.
8.Turning,broaching and engraving can be done with one machine by high speed


  • FOB Price: US $0.5 - 9,999 / Piece
  • Min.Order Quantity: 100 Piece/Pieces
  • Supply Ability: 10000 Piece/Pieces per Month
  • Product Detail

    video

    Product Tags

    One Axis CNC Wood Turning Lathe is a used for bowl sharps, vases, goblets, cups, mugs, table legs, baseball bats, wood crafts and various cylindrical woodturning projects. Now the best wood lathe for sale at an affordable price.

    Product Descriptions

    5

    Parameters of automatic wood lathe machine

    Item Parameter
    Max. diameter 20-300mm
    Max. Working length 2000mm
    Quantity of spindle 1
    Quantity of knife 2
    Max.feeding speed 40mm/s
    Processing accuracy 0.00125mm
    Spindle motor power 4KW/5.5KW
    Voltage 380V/50Hz/3Phase (Or 220V/50Hz/Single/3 Phase)
    Compatible software autoCAD,type3,artcam,etc.
