Hot Sale CNC 1325 Auto Tool Change Wood Carving Machine ATC CNC Router
Features of the Circular ATC Router
- 1300*2500mm, 1500*3000mm, and 2000*3000mm standard size (Special size available upon to user request)
- The internal structure of the bed adopts the aircraft metal honeycomb structure, which is welded by a number of rectangular tubes. Through 600ºC heat treatment to keep stronger and more solid. High strength, stability, tensile strength, ensuring 20 years of use without distortion.
- Widely used, including engraving, milling, chamfering, side milling, drilling, cutting, grooving, etc.
Apart from our own products, APEX also provide OEM services and accept customized orders to suit your needs.
Below is the common parts for your reference.
Leadshine 1.5kw Motor and Drivers
Heavy Duty Body (more than 10mm)
High speed, big power. Motor's max torque can reach 350% which may shorten speed up and slow down time.
Hundred times special vibrate experiments with enhanced welding technicals, ensure the lathe won't deform during long-term working hours.
ATC HQD 9kw Air Cooling Spindle
Taiwan Delta
Air cooling spindle with perfect cooling effect, long life and high stability with 24000RPM.
Excellent control frequency and adjust spindle speed,keep bigger torque when speek of spindle lower or higher.
Taiwan Syntec Control System
Double-Deck Vacuum Table with Chamber
Professional control system for ATC cnc machine, extend maximum performance of cutting and engraving.
Support G code and M code format with less fault and high stability.
An air chamber between two tables, when the vacuum pump turned on, there is an instant adsoption and release function.
On the table, smaller adsorptive blocks and embedded slot design. We fully learned to keep biggest sucktion for the workpiece, and promise you can cut most narrow materials up to 20mm width.
Parameters of the ATC CNC Router
| Standard Configurations | |
| Model&Name | APEX-1325ACT |
| Brand | APEXCNC |
| Reducer | Japan Shimpo reducer |
| Rail Guide | Taiwan HONGTAI 25 guide rails |
| Invert | Fuling Inverter |
| X,Y axis Transmission | Rack drive |
| Rack | Atlanta 1.5m |
| Limit Switch | Japan Omron limit switchLimit switches at both ends of the X & Y axis |
| Dust Collector | 3KW dust collector with double bag |
| Filter | Yes |
| Pins Alignment | Yes |
| Protective Sheet | Yes |
| Tool Holders & End Mills | Yes |
| Tool setting Gauge | Auto |
| Lubrication System | Auto |
| Technical Parameters | |
| Working Area | 1300*2500*300mm |
| X,Y,Z Traveling Positioning Accuracy | ±0.01/2000mm |
| MAX. Traveling Speed | ≥50000mm/min |
| MAX. Cutting Speed | ≥25000mm/min |
| Commend Code | G Code |
| Working voltage | AC380V 3Ph |
| Interface | USB |
| Rated power | At most 18KW·H |
| N.W./G.W. | 1600/1800kg |
| Packing size of machine and auto feeding(mm) | 1650*3000*1700mm (removing gantry) |
| Running environment | Temperature:0℃~45℃ Relative Humidity: 30%~75% |
Customers Samples Photos
The sucessful samples photos of our customers applications.
If you are in below area, just choose APEX-1325 ATC CNC Router as your assist.
APPLICATIONS
In furniture, advertising, mold, decoration, construction and other fields and industries.
In terms of functions, it can cut, engrave, drill, mill and groove.
MATERIALS
In regard to materials, ATC CNC router can process various wood materials, plastics, stone, soft metals and composites.
Wood: natural wood, plywood, soft wood, hard wood, fiberboard, particle board, melamine board, LDF, MDF, chipboard
Plastic and rubber: acrylic, ABS, HDPE, PVC, LDPE, UHMW, resin, double-colored board, PP, EVA
Stone: granite, marble, slate, basalt, pebbles, ceramic, porcelain, natural and artificial stones Soft metal: aluminum, brass, copper, mild steel
Composite: aluminum plastic composite, copper composite, titanium composite, zinc composite
