Two Heads CNC Router Wood Carving Furniture Making Machine

Short Description:

This is an easy operation woodworking engraving machine. It can meet most of your processing needs in the non-metal industry without high purchase and use costs. Besides, it is also the ideal carving equipment for the woodworking industry. low price and long service lifetime.


Product Detail

video

Product Tags

Two spindles wood CNC machine with 4×8 table size is designed for three dimensional wave plate processing, cupboard doors, wooden doors, window processing, cabinets and panels, computer table and furniture auxiliary processing. Now the 4×8 wood CNC machine for sale at a low price.

Product Descriptions

1 (6)
Advantages of Dual Spindles wood CNC machine with 4×8 Table Size:

4×8 wood CNC machine with two spindles is customized for changing the tools within 2-4 pieces. It’s not only economic, but also can realize automatic tool change, save the time of manual tool change and improve the working speed and precision. And it can cut two work pieces at the same time to reach the same effect. What’s more, this wood CNC machine could mirror-sculpture (same engraving path, but in opposite directions) by changing the cables, which is widely used for door making.

Applications of Dual Spindles Wood CNC Machine with 4×8 Table Size:

1. Woodworking industry:
Three dimensional wave plate processing, cupboard doors, wooden doors, window processing, video game cabinets and panels, computer table and furniture auxiliary processing.
2. Advertising industry:
Advertising signs making, logo production, acrylic, plastic cutting, production of decorative materials, forming system module, etc.

Technical Parameters of 4×8 Wood CNC Machine with Dual spindles:

Model APEX1325
Working Size 1300mm*2500mm*200mm
Body structure Steel tubes
X, Y Structure rack and pinion drive
Z Structure Ball Screw/option gear wheel
X, Y Resolution <0.01mm
Max Moving Speed 32000mm/min
Max Engraving Speed 20000mm/min
XYZ traveling positioning accuracy 0.03/300mm
XYZ repositioning accuracy 0.03mm
Spindle power 3kw/4.5kw/5.5KW (can be choices)
Spindle Speed 24,000rpm
Table style T-slot table (option vacuum table)
Dust collection Can add or not
Voltage AC220V/50HZ/60HZ,380V/50HZ
Drive type Stepper (Option servo)
Working Dictate G Code ,HPGL
Operating system DSP control system
Interface USB
Flash memory 128M(U Disk)

Features of 4×8 Wood CNC Machine with Dual spindles:

1. The whole CNC wood machine is welded with thick square seamless steel structure, the stability is excellent, not easy to be deformed.
2. Three axis adopt high precision square orbit, X and Y axis adopt rack and pinion transmission, fast working, high efficiency and low cost. Z axis adopts Taiwan TBI ball screw transmission with high precision and long life time.
3. High power spindles have constant power, low noises and super strong cutting force, which improve working efficiency greatly.
4. Famous brand drivers and motors have characteristics such as powerful strength, high machining speed.
5. Well compatibility: CAD/CAM designing software e.g. Type 3/ Artcam/ Castmate/ Wentai, etc.
6. The 4×8 wood CNC machine has the function of re-carving after break point and power failure.
7. The4x8 wood CNC machine has the function of forecasting process time.
8. Adopting advanced NCstuido system, convenient operation.
9. Perfect oil lubrication system makes maintenance much easier. And electric limit switch on all axis, make sure the machine running well.
10. Independent control box make control easier.
11. We will provide you a set of cutter, and a tool box with other necessary accessories.

Projects of 4×8 Wood CNC Machine with Dual spindles:

4x8 Wood CNC Machine Projects
Dual Spindles Wood CNC Machine Project

SERVICE for Dual Spindles Wood CNC Machine with 4×8 Table Size:

1. Technical supports and suggestions before you order a CNC wood machine according to your work piece.
2. Professional instruction for the operation of the machine.
3. One year warranty, we will provide the consumable parts at cost price after the warranty period.
4. Our technician will come to your workshop if the problems can not be fixed through Internet or phone communications.
5. 24/7 technical support by email or calling.

International Shipping Around the World

All the CNC routers can be shipped worldwide by sea, by air or by international express logistics via DHL, FEDEX, UPS. You are welcome to get a free quotation by filling up the form with name, email, detailed address, product and requirements, we will shortly contact you with the full information including the most suitable delivery method (fast, secure, discreet) and freight.
