Stone CNC Router 2021 new design model

Short Description:

It is mainly used in engraving stone, marble, granite, black stonge, bluestone, jade stone, crystal, glass, organic glass Floor tile and ceramic tile,  plastic, chemical synthesis board,  PVC board, bamboo ware,  aluminum-plastic panel, metal, etc.,  line carving, 2D engraving, 3D engraving, 3D relief, Cutting, drilling, polishing, etc.

We are manufacturer of CNC router machines,which have widely application of many materials like wood, acrylics, stone, metal, plywood etc, with professional manufacturing process, and rich experience engineers for R&D,  manufacturing, sales, and after sales service. Thus we can do both OEM and ODM service well, and client site machine installation, and technique support is available too. Now we are looking for agents and distributors worldwidely, welcome to visit or talk on line about mutual cooperations. Please talk with our international marketing manager about the cooperation, Mary Jane, whatsapp/cell phone: +(86) 15169183960.


Product Detail

video

Product Tags

Affordable stone CNC router STS1325 is suitable for carving natural marble, granite, bluestone, sandstone, artificial stone, tombstone, milestone, headstone, etc. Now the best stone CNC router for sale at low price.

Product Descriptions

Stone CNC Router
stone CNC router Advantages:
1. T type heavy duty machine structure, good weight bearing capacity, not easy to deformation, the special machine bed design, can bearing more than 2000kgs materials.
2. The special designed Zaxis, can increase the stone relief accuracy, can solve the Zaxis belt or ball screw breaking problem thoroughly.
3. The water proof and dust proof system for X Y Zaxis, can protect all the parts, reduce the machine fault, enlarge the life time.
4. High-performance driven motor to ensure that the machines high speed and accuracy.
5. Using well-known domestic brands of water-cooled brushless spindle, low noise, strong cutting ability to ensure the long time working.
Stone CNC router Technical Parameters:

Model APEX1325
Working Area 1300x2500x300mm
Max Travel Speed 25m/min
Max Carving Speed 8m/min
Resolution 0.005mm
Repositioning Accuracy 0.05mm
Spindle Power 5.5KW Water Cooling
Spindle Speed 0-24000rpm/min
Power 1500W (Not Including Spindle)
Working Voltage AC380V/50Hz
Control System DSP Control
Operating System Windows XP/Windows 7/Windows 8/Windows 10
Motor Type Stepper Motor
Drive Type X,Y Rack and Pinion, Z ballscrew
Clamping Type Profile Pressure Plate, Stainless Steel Water Tank
Run Rail Hiwin Square Rails

Stone CNC Router Features:
1. Lathe bed welded with thick channel steels and square tubes;Processed by high temperature tempering treatment and vibrating stress relief(VSR) to reduce residual stress,good stability,no deformation.
2. Using the higher precision rack pinion transmission, higher accuracy, fast speed and powerful.
3. High-speed water cooling spindle and high performance subdivision driver ensure to work stably for long time.
4. With practical and easily-learned software, it can conveniently check the moving path of tool, and adjust the processing depth of Z axis and the speed of motor.
5. Designer perfectly, select the best machine accessories to minimize the failure rate preferred .
6. Breakpoint specific memory, power outages continued carving, processing time forecast, and other functions to ensure that accidental processing.
7. With water tank and double water cooling system, high efficient works.
Stone CNC Router Applications:
1. The affordable stone CNC router is suitable for natural marble, granite, bluestone, sandstone, artifical stone, tombstone, milestone, ceramic tile, jade, crystal, ceramics, glass, plastic, wood, bamboo, cambered surface, sphere, stainless steel, iron, copper, aluminium, titanium alloy, etc, it can do 3D embossment, line engraving, bevelling, drilling and 2D carving.
2. Granite stone can be layered carving to 3mm.
3. Marble, bluestone can be carved to 3mm on time.
4. The best stone CNC router can carve characters, letters, pattern, intaglio, rilievi, handwriting, ancient calligraphy, abrazine colored drawing, flat carving colored drawing on stone, glass. The depth can be controlled optionally to reach the artistic effect.
Stone CNC router project
Granite CNC router project
Tombstone CNC router project
Stone CNC Router Projects:
Stone CNC Router Projects
Stone CNC Router Service
Installation and Debugging
Customers can get detailed operation manual and instruction video of our CNC stone router. We will make sure that customers can operate machines skillfully.
Training
Customers can get free technical training. Mainly training are as follow:
1. Software operation.
2. Machine operation and maintenance.
3. Instruction of technical parameters, as well as their setting ranges.
4. Solutions for common problems.
Equipment Maintenance
1. One year free maintenance, lifelong caring.
2. Free technical consultant and software updating.
3. Customer Service responding in 2 hours.
4. Continuous support with software and hardware after free maintenance.
Guarantee
The guarantee period shall be 12 months counting from the date on which the machine arrives destination port. Except the damage artificially, we are responsible for offering the fittings free of charge during the guarantee period, but you must send the damaged fittings to us by courier with your charge before we send back the alternative fittings to you. After the guarantee of quality period, the parts required to repair or change, if any, shall be paid.
International Shipping Around the World
All the CNC routers can be shipped worldwide by sea, by air or by international express logistics via DHL, FEDEX, UPS. You are welcome to get a free quotation by filling up the form with name, email, detailed address, product and requirements, we will shortly contact you with the full information including the most suitable delivery method (fast, secure, discreet) and freight.
