China Made 6060 Automatic CNC Milling Machine Metal Mould CNC Router Machine

Short Description:

APEXCNC Brand mould cnc milling engraving machine mainly used for all kinds of metal materials, such as aluminum, copper, stainless steel, carbon steel, fiber glass etc.
the standard model have APEX4040 , APEX6060, APEX6090, machine can be customized.

Product Detail

Product Tags

Mould cnc milling machine features:
#ATC type, linear auto tool changer or circular tool changer for choose
# Whole machine cast by iron, very strong, table moving, high precision.
# Imported Hiwin square rails and TBI ball screw for 3 axis.
# Working area 600*600*200mm, Z axis zone can according your need make it.
# Japan Yaskawa servo motor and drivers,leadshine hybrid servo motor for option.
# Syntec controller, TK100 controller, DSP control system and NC Studio for option.
# Machine with lubrication system, spindle cover, Japan OMRON limit switch and Schneider electrical components.

mould cnc router

Standard Configuration
Model & Name APEX6060
Working Area 600*600*300mm
Control system Intelligent integration NK280 control system
Spindle 5.5KW / 7.5KW ATC water cooling spindle
Auto tool changer Circular auto tool changer 12 tools
Motor and drivers Japan YASKAWA servo motor and drivers 750W
Rail guide Taiwan 25 HIWIN square rails
Ball Screw Taiwan TBI grinding ball screw
Inverter Taiwan Delta inverter
Electronic components France Schneider electronic components
Software Artcam software
Limit switch Japan Omron limit switch
Working Dictate G-code
Water cooling system Included
Technical Parameter
Working area 600*600*300mm
Spindle power 5.5kw / 7.5kw ATC water cooling spindle
Rotary axis diameter 200mm
Spindle speed 24000RPM
Working Accuracy (mm) ≤0.01mm
X,Y,Z Traveling Positioning Accuracy (mm) ≤0.01mm
Max. Idling Speed 60m/min
Max. Working speed 40m/min
Commend Code G Code
Diameter of Cutter φ3.175-φ12.7
Cooling Mode Water-cooling
Working voltage 380V 3P 50HZ


Packing and shiping
1.Outside package: Standard marine export plywood case.
2.Inner package: Three layers in total; EPE pearl cotton film+PE stretchy film.
3.Improved package, much more strong and environmental protection.
4.We can also make package according to your requests.
Delivery Detail: Shipped in 10-15 working days after payment.


Dear Sir/Madam,
This is Mary Jane from Apex Machinery company, glad to know you have interest of CNC router products.

Our company is a professional cnc router manufacturer with 12 years experience,  we have 35 well trained workers,  35000 m2 workshop, we have been a cnc machine big agencies years vendor of  cnc routers and with CE, SGS, COC, BV certificates, so we have confidence to provide superior quality and competitive offers for global valued customers.

Our main products cover wood furniture manufacturing, sign advertisement process, metal plate and tube process, laser marking,metal and wood milling area, please contact us for our e-catalogs.

If any product meet your demand, please contact us for further information.

We’re sure your any inquiry or requirement will get prompt attention.

Best regards,
Mary Jane
