Linear Atc CNC Router Machining Center with Saw and Drill Unit for Invisible Panel Furniture

Short Description:


Product Detail

Product Tags

Feature
9.0KW Spindle

9.0KW high power ATC spindle is suitable for high-speed cutting in a long time, and various kinds of carving work.

Imported drill unit/boring head and 4 axis saw blade device

4 axis saw blade device is very suitable for grooving of Lamello clamex P series connectors. The drill unit/boring head equips multiple drills, suitable for efficiently drilling installation holes of three in one or two in one connector in panel furniture production.

Innovative raw material fixing design

Double layers grid type vacuum adsorption working table with several zones, to ensure that the small board processing without changing position.
Strict quality inspection standards

During the production process of the whole machine and before leaving the factory, it accepts strict quality inspection control and processing test to ensure that the backboard grooves and the front and back holes are accurately drilled. Ensure that the backplate slot and the front and back holes are accurately drilled.

pneumatic 4 heads ATC cnc router

Technical parameters
Model No. LDA48-1325

Working size: 1220*2440mm, other customized sizes are acceptable

Spindle: 9.0KW Air cooling ATC spindle

Quantity of tool holder: 4/6/8/12/16 PCS

Drill unit/boring head: Imported

Motor of 4 axis saw device: Original from Taiwan

Motor and driver: Delta servo motors and drivers (Yaskawa is optional)

Working table: Double layers A+ PVC board grid type vacuum working table

Control system: SYNTEC or Delta

Vacuum pump: yes

Dust collector: yes

Max. moving speed: 80m/minute

Max. working speed: 25m/minute

Type of transmission: X/Y axis rack, Z-axis ball screw. X/Y/Z axis both adopt ball screws is optional.

Working voltage: 3PH 380V 50/60Hz

Total Weight: 3000 KG

Total power: 25.5KW

Automatic loading and unloading tables are optional, design of two working tables is optional

Solvable processing

1. drilling: Adopts different diameter drills to drill different sizes hole on various boards.

2. grooving: With suitable tools to do grooving or slotting, it also can finish Clamex joint slots for Lamello.

3. cutting: Suitable for the regular shapes and irregular shapes cutting, also can do edging.

4. milling: Adopts different shapes CNC milling tools to achieve beautiful designs.

5. hollow-cutting: Solve production of the carved screens, separating boards, or other products that need to be hollowed cut.

6. carving/engraving: 2D carving design on wooden, composite, or other soft raw materials. If you need to do 3D design, please contact us to inquire about other 4/5 axis CNC machines for you.

1619507717(1) 1619507740(1)
