3 Axis CNC Router Wood Carving Machine for MDF Kitchen Cabinet Furniture

Short Description:

* Nc Studio control system, High engraving accuracy, and cut accurately.

* Stepper driving, or servo driver optional

* TBI Square rail

* T-slot table surface, can fix the materials easily


Product Detail

video

Product Tags

This is promotion type APEX1325 cnc router for agent customers, T-slot table, NCstudio control system, step motor and drivers, 3.0kw water cooling spindle etc.

Also have APEX1530, APEX2030, APEX2040 ETC. Machine model can be customized.
2 Years warranty the whole life technical support, online training also can send engineer do training at foreign factory.

DSC00722





Technical Parameters:

No. Description Parameter
1 X, Y, Z Working Area 1300mmx2500mmx200mm
2 Table Size 1450mm×2940mm
3 X, Y, Z Traveling Positioning
Accuracy
±0.02/300mm
4 X, Y, Z Repositioning Accuracy ±0.02mm
5 Table Surface T-slot table
6 Frame Welded steel tube structure
7 Inverter: Chinese Fuling Inverter/Taiwan Delta Inverter
8 Spindle CS water colling spindle/
Italy HSD air cooling spindle
9 Limit switch Japan Omron limit switch
10 Oil LubricationSystem Manual
11 X, Y Structure Rack and Pinion Drive, Hiwin Square Rail
12 Z Structure Hiwin Square Rail and Ball Screw
13 Max. Power Consumption 5~7KW
14 Max. Rapid Travel Rate 33000mm/min
15 Max. Working Speed 25000mm/min
16 Spindle Power 3.5/4.5/5.5/6 KW
17 Spindle Speed 0-24000RPM
18 Motors 450B stepper/Yaskawa servo
19 Working Voltage 380V/220V
20 Command Language G Code
21 Operating System NCstudio control system
22 Computer Interface USB
24 Collet ER25
25 X, Y Resolution <0.03mm
26 Software Compatibility Artcam Software
(Option: Type3 Software)
27 Running Environment
Temperature
0 - 45 Centigrade
28 Relative Humidity 30% - 75%
29 Packing Size 3150mmX2100mmX1900mm
30 N. W. 1500KG
31 G. W. 1800KG
32 Optional Parts Air Cooling Spindle or Water Cooling Spindle
Syntec Control System
Dust Collector
Vacuum Pump
Rotary System
Mist-cooling System

Application Industry and Materials:
Woodworking Industry: CNC router can be used for solid wood furniture, mahogany furniture, MDF paint doors, solid wood doors, composite doors, cupboard doors and windows, beside cabinets, folding screen etc.
The advertising Industry: CNC router can engrave all kinds of signage, logo products, trademarks, nameplates, badges, decorative gift, embossed
Medals, certificates, souvenirs, photo frames, furniture decoration, PVC plates, PCB boards(drilling and engraving), Double color boards, acrylic etc.
Artwork Industry: In the wood, bamboo, organic board, double color plate, crystal and other materials on a variety of exquisite patterns and text engraving.
Exhibition Industry: Showcases, etc.

1 (2)

Packing & shipment:
Save space as much as possible for container loading.
Inside: Water-proof Plastic Film Package With Foam Protection
Outside: Solid Seaworthy Wood Box Package
Below: Steel Tube
1) Foam and wrapping film on the surface of the machine inside. Rain-proof, Dust proof.
2) Standard export plywood case. Upwards, moistureproof shipping marks. Safety guaranteed.
3) Fumigation-free
4) With shipping mark if you like.
5) Outside: Marked packing size, model, weight and other information
