High Speed 1325 4 Axis CNC Router Atc Engraving Cutting Machine for Wood Stone

Short Description:

Brief Introduction of 4 axis cnc router
♦ The spindle can rotated 180 degree, specially designed for curve surface cabinet,doors and indoor decoration. and also for some mold prcessing.
♦ It can be used for mass-processing with Vacuum holding way and dust collector.
♦ Equipped with top quality components for the machine, such as HSD ATC spindle, and the spindle Yaskawa servo motor & Taiwan Delta Inverter, Becker Vacuum pump,


  • FOB Price: US $0.5 - 9,999 / Piece
  • Min.Order Quantity: 100 Piece/Pieces
  • Supply Ability: 10000 Piece/Pieces per Month
  • Product Detail

    video

    Product Tags

    Moving table CNC router machine with 16 pieces automatic tool changer is used for high precision engraving and cutting on wood, brass, aluminum, plastic, acrylic, MDF and other similar materials.

    Product Descriptions

    The CNC router machine with 16 pieces automatic tool changer has a stationary bridge with moving table. The automatic tool changer CNC router machine with moving table is designed to increase productivity while maintaining an open-style machine for ease of use. The moving table CNC router machine is used for cutting and engraving on wood, brass, aluminum, plastic, acrylic, MDF and other similar materials.
    We use top quality components for the ATC CNC router machine with moving table, such as HSD spindle, Yaskawa servo motor, Delta Inverter, Hiwin linear and so on, to keep the machine in best condition even after working for many years. With phenolic T-slot and vacuum combined table, not easy to deflect, you can do variety of high-precision works.
    0
    Features of Moving Table CNC router machine with automatic tool changer:

    1. Italy HSD spindle: original famous brand from Italian.
    2. Taiwan SYNTEC control system: It is from Taiwan with high performance and competitive price.
    3. Japan Yaskawa servo motor and drives: They are from Japan with high precision and long life.
    4. HIWIN linear guide rails: made from Taiwan,used for linear reciprocating stadium.
    5. Schneider electrical components: original brand from France.
    6. Japan Omron Switch with long life.
    7. Disc-type ATC with 16tools, no need to change tools manually during working.
    8. Applicable to workpieces which need many different tools to finish. Intelligent controlling with high efficiency.
    9. Whole cast steel structure thickness to 8mm.
    10. APEX Reudcer from Taiwan: More powerful and higher precision.
    11. T-Slot table with vacuum table: Use clamp or pump to fix materials.
    12. Moving table.

    Applications of Moving Table CNC router machine with automatic tool changer:
    Moving Table CNC router machine with automatic tool changer is suitable for the wave board processing, wooden door, screen, craft, window processing and different kinds of furniture assistance processing.
    Automatic tool changer CNC router machine with moving table is also suitable for the aluminium board, plastic board, artificial marble as well as the light metal industry.
    Techncial Parameters of Automatic Tool Changer CNC router machine with moving table:

    Description Parameter
    X,Y,Z axis working area 2500* 1300*400mm
    X,Y,Z Traveling Positioning Accuracy ±0.03/300mm
    X,Y,Z Repositioning Accuracy ±0.03mm
    Table surface Vacuum Combined T-slot
    Frame Big steel tube structure
    Control system Taiwan Syntec control system
    Spindle Power 9.0KW HSD air cooled spindle
    spindle rotating speed 24000r/min
    Tool type Linear type
    Guide rail HIWIN square guide rail
    Motor AC Yaskawa servo motor
    Max. Power Consumption (Without Spindle) 4.5Kw
    Max. Rapid Travel Rate 50000mm/min
    Max. Working Speed 30000mm/min
    working voltage AC380V/3PH/50HZ
    Command Language G Code
    Computer Interface USB
    Operational System Software Type 3/Artcam
    Gross Weight 1900KG
