3 Axis Shoes Mould Making Machine Metal Mold Engraving CNC Router
CNC metal engraving machine for iron, brass, copper and steel is used for machining shoes designs on metal materials. It’s one economic metal engraving machine with full automatic CNC programing.
Demonstration Video
Product Descriptions
| Standard Configuration | |
| Model & Name | APEX6060 |
| Brand | APEX |
| Working Area | 600*600*200mm |
| Control system | DSP / NCstudio control system |
| Spindle | 3.0KW water cooling spindle |
| Motor and drivers | Leadshine servo motor and drivers |
| Rail guide | Taiwan 25 HIWIN square rails |
| Ball Screw | Taiwan TBI grinding ball screw |
| Inverter | Fuling inverter |
| Electronic components | France Schneider electronic components |
| Software | Artcam software |
| Limit switch | Japan Omron limit switch |
| Working Dictate | G-code |
| Water cooling system | Included |
| Technical Parameter | |
| Working area | 600*600*200mm |
| Spindle power | 3.0KW water cooling spindle |
| Spindle speed | 24000RPM |
| Working Accuracy (mm) | ≤0.01mm |
| X,Y,Z Traveling Positioning Accuracy (mm) | ≤0.01mm |
| Max. Idling Speed | 60m/min |
| Max. Working speed | 40m/min |
| Commend Code | G Code |
| Diameter of Cutter | φ3.175-φ12.7 |
| Cooling Mode | Water-cooling |
| Working voltage | 380V 3P 50HZ |
CNC Milling Machine Main features
1. Whole cast iron structure, the body will not transform for long use.
2. X Y Z use 25mm HIWIN linear square guide rail, it is more stable than the normal round one.
3. X Y Z transmission use high precision ball screw, avoid the spindle suddenly up and down.
4. Gantry fixed,table move design make the machine more precise.
5. DSP controller system,higher precision, easier and more convenient to operate.optional TK100 / Ncstudio/ Syntec control system
6. Japan yaskawa servo motor and driver, break-point memory makes sure accidental workng and avoid the waste of materials.
7. X axis has steel cover,keep the machine clean and long life.
