Hot sale 6090 Desktop CNC Router Machine

Short Description:

Advantage of Machine
1) Water cooling spindle, with high precision, long life time, steady working, easy to start up.
2) Taiwan Hiwin linear square guide rail, self-lubricating sliding block. It ensures equal
force in all directions and accuracy and strength of the machine.
3) Taiwan TBI ball Screw transmit, ensured high accuracy and stable when working.
4) Stepper motors and Drivers, 3 sets in total, with big torque, ensure machine stable.
5) DSP controller system with USB interface,working without connecting with computer
during working and easy to control.

Send email to us

Product Detail

video

Product Tags

Small CNC router machine is designed for someone who needs multiple tools for CNC machining projects without enough space for a larger CNC router machine.

Product Descriptions

Small CNC router machine with ATC system is oneentry-level CNC router for small-envelope projects. It is small enough to work for someone without enough space.

Main Features of small CNC Router Machine with ATC System:
1. The spindles have water-cooling or air-cooling for different usage, If you need to cut aluminum, it is better to use water-colling spindle. If only for wood projects, the air-cooling spinlde is better.
2. The control systems have Taiwan Syntec system, DSP control system and Mach3 system, it is depend on the price and functions.
3. T-slot table and vacuum table for choose.
4. Welded structure by thick square steel stabilized under high temperature, ensures minimum distortion, excellent rigidity and powerful strength.
5. Automatic lubricating system, one touch can finish periodic maintenance easily.
6. Internationalized directives ensure that it is compatible with CAD / CAM software like Type3 / Artcam / Castmate / Proe / UG / Artcut.
Applications of Small CNC Router Machine with ATC System:
Small CNC router 6090 is suitable forAcrylics, artificial stone, artificial marble, woods, bamboos, organic boards, double-color board, PVC board, aluminum, brass and other materials processing.
Small CNC router 6090 is used in Woodworking industry, stone industry, advertising industry, artwork or decoration industry, electronica industry, mold industry and music industry, etc.
Technical Parameters of Small CNC Router Machine:

Model	APEX6090C
Working Size	600900200 mm
Machine Body	Welded square tube
Table Surface	Vacuum table+5.5kw vacuum pump
Z Axis	Taiwan TBI ballscrew transmition
X,Y Axis	Helical rack and pinion transmission
Machine color	Can be customized based on your requires
Spindle	5.5kw Water Cooling spindle (2.2KW, 9KW for option)
Spindle Speed	24000 RPM
Drive Motor	Yaskawa servo motor
Max. Rapid Travel Rate	16000 mm/min
Max. Working speed	8000 mm/min
Control System	DSP controoler
Software	Type3, Artcam, Ucancam
Command	G code
Machine precision	0.01 mm
Repositioning precision	0.03 mm
Working Voltage	AC 220/380V

Projects of Small CNC Router Machine with ATC System:

The wood CNC router working area can be customized based on your work, our standard size is 600*900mm, 1200*1200mm, 1300*2500mm, 1500*3000mm and 2000*4000mm.

International Shipping Around the World
All the CNC routers can be shipped worldwide by sea, by air or by international express logistics via DHL, FEDEX, UPS. You are welcome to get a free quotation by filling up the form with name, email, detailed address, product and requirements, we will shortly contact you with the full information including the most suitable delivery method (fast, secure, discreet) and freight.
