1530 Fiber Laser Generator CNC Metal Pipe/Tube Laser Cutting Machine

Short Description:

Fiber laser cutting machine adopting world famous Germany IPG fiber laser source and Raycus laser source,Raytools cutting head and dynamic focus system, it can cut and punch different kinds of metal material with high precision and high speed. Since laser is transmitted by fiber , it is no need to maintenance or adjusts the laser optical path , it greatly reduces the machines fault rate and prolongs the working life. Large format cutting area meets the demands of various kinds of metal processing .


Product Detail

video

Product Tags

CNC metal pipe/tube laser cutting machine with fiber laser generator can meet all kinds of shaped tubes and pipes cutting, such as round tube, square tube, rectangular tube, flat tube, flange beam, channel beam, U-tube and various type of shaped tubes and pipes cutting.

Demonstration Video

Product Descriptions

1 (4)

Advantages of CNC Metal Pipe/Tube laser cutting machine with Fiber Laser Generator



1. Max cutting length of 6m and diameter of 220mm.

2. Method of working: Fiber Laser cutting.

3. Cutting obligue section on the end of pipe.

4. Cutting for various-angle groove face.

5. Cutting with square oval hole on the square pipe.

6. Cutting off steel cylinder pipe.

7. Cutting multiple special graphics on the pipes and cut off pipes.



Technical Parameters of CNC Metal Pipe/Tube Laser Cutting Machine with Fiber Laser Generator



Model APEX60MA
Laser Generator Fiber Laser
Cutting Diameter Dimension 20mm-220mm
Cutting Length Dimension 6000mm
Laser Wavelength 1064nm
Laser Power 1000W (other powers for option)
Cooling Method Constant temperature coolong system
Repeat positioning accuracy
