6090 Portable UV Printer Hot Selling New Model

Short Description:

Work Process
1. Pre-treatment
For materials such as metal, glass and some of the acrylics need to have pre-treatment before print.
Put the coating on by brush or non-dust cloth, leave for 1-2 minutes to dry.
2. Check the distance between the print head and the flatbed
Distance about 2-3mm. (The thickness of a coin)
3. Print positioning frame
Select the PRN position frame in PrintEngine, click print.
4. Set the objects
Put the objects into the positioning frame, check the height again.
5. Print
Find the positioning frame & Image PRN and print.


Product Detail

Product Tags

Machine Maintenance:
1.Weekly cleaning and maintenance of X and Y axis guide rail and lifting gear and rack
Clean X axis guide rail and Y axis work platform with cloth, add liquid lubricating oil to X axis guide and Y
axis guide, add grease or solid lubricating grease to lifting screw.
2.Prevent liquid splashing inside the machine
Ink and cleaning liquid are highly corrosive, do not touch the electrical components and wires. If ink,
cleaning liquid or other liquids are splashed accidentally, power off and wipe it off immediately.
3.Clean grating strip every week
There are many scales on the raster. If the scale is covered with ink and dust for a long time, it will lead to
printing fuzzy size deviation, which will affect the final printing effect.
4.Opened ink must be used in a timely manner
If not must be sealed, because this will cause the evaporation of ink or contact with the air and
deterioration, causing print head blockage, and may affect the color fastness of the printed picture on the
product.
5.The ink bottle on the machine must be gently shaken every two days
Shaking time about one minute. To ensure the fluency of the ink and prevent ink precipitation and block
the print head.
