3D 1390 Laser Cutting Machine for sale with affordable price

Short Description:

This machine can cut and engrave on the acrylic, the max thickness can cut and engrave on the acrylic is: 20mm. We have many size of laser machine, as working size: 1300x900mm, 1300x2500mm, 600x900mm, 1400x1000mm 1600x1000mm and so on. Laser tube has 60w, 80w, 100w, 120w, 150w, using the Beijing RECI, or Chengdu Weegiant, having the honey nest table and the blade table.


Product Detail

video

Product Tags

This machine can cut and engrave on the acrylic, the max thickness can cut and engrave on the acrylic is: 20mm. Laser tube has 60w, 80w, 100w, 120w, 150w, using the Beijing RECI, or Chengdu Weegiant, having the honey nest table and the blade table.

Demonstration Video

Product Descriptions

22



Advantages of 3D Robotic laser cutting machine for Metal with Fiber Laser Source



The ABB industrial robotic arm from Japan will assist the 3D laser cutting machine to make flexible 3D dynamic cutting of multi-dimensional and multi-angle for metals with different thickness.



1. The 3D laser cutting machine is perfectly integrated with the world famous ABB industrial robot and fiber laser cutting technology, which can realize the maximizing automated production. It will represent the supreme laser cutting technology.

2. 6 axis co-ordination makes a large working area, which will reach a long distance, in addition, it has great ability of spanning and high load-bearing capacity to ensure the cutting process along 3D path within the working space.

3. Due to slim robot wrist and the compact structure, so the 3D robotic laser cutting machine can realize high performance operation in a limited space.

4. Laser cutting speed can be adjusted to achieve the best machining precision with high yield.

5. Long lifespan, long routine maintenance intervals, low-noise.

6. The robotic arm can be controlled by handheld terminal.

7. Packaging, handling, welding and other functions can be realized by changing hardware and modifying the program.



Technical Parameters of 3D Robotic Laser Cutting Machine for Metal



Model APEX1390
Laser Source Raycus (IPG for option)
Laser Power 1000W
Laser Wavelength 1080nm
Robot ABB Robotic Arm (FANUC Robot for option)
Driving System Japan Yaskawa Servo Driver
Laser Head Raytools 3D Laser Head
Repeated positioning accuracy 0.05mm
Graphic Format Supported AI, PLT, DXF, BMP, DST, DWG, LAS, DXP
Installation Floor stand/ Inversion type / wall-mounted



Auxiliary System for 3D Robotic Laser Cutting Machine



Cooling system Dual-temperature with purification system chiller
Laser source cooling system Air conditioning
Auxiliary gas system Three gas source dual-pressure gas
Laser cutting head Capacitive follow-up focus



Features of 3D Robotic Laser Cutting Machine for Metal with Fiber Laser Source



1. Laser source: High-performance fiber lasers, high efficiency, low cost of comprehensive use.

2. The cutting head is equipped with robots from ABB, the world-renowned robot brand. The robot is agile, powerful and built-in quick move. It can improve the path precision and shorten the beat time. The robot software can detect the internal load of the robot effectively. Overload, extended service life, flexible integration, flexible production, it can only control, compact and efficient.

3. 3D laser cutting head: Optional use of the international top brands of 3D laser cutting head, which will realize the laser beam always in the focus position to ensure the cutting effect. It offers standard with the same cutting capacity of homemade laser cutting head, more economical and more affordable.

4. Auxiliary blowing system: The system integrates high pressure air, nitrogen, oxygen three gas source structure with high and low pressure conversion gas path.

5. Lubrication system: The 3D robotic laser cutting machine is equipped with manual lubrication system to reduce the wear of moving parts and ensure the movement speed of the whole laser machine.



Applications of 3D Laser Cutting Machine with Robotic Arm for Metal



3D robotic metal laser cutter is available for metal cutting and molding of carbon steel, stainless steel, mild steel, aluminum, alloy, copper, iron, brass with advantage of High speed, High precision, High efficiency and High cost performance. This 3d laser cutting machine is the first considering metal cutting machine for metal working industry.



3D robotic metal laser cutting machine can be used for different profiles, including 3d curved metal parts, round tubes, square tubes, rectangular tubes or triangular tubes, oval pipes, H beam or D-type.



3D robotic laser metal cutting machine is widely used in electronic components, automotive parts, aerospace technology, aircraft manufacturing, rocket manufacturing, robot manufacturing, elevator manufacturing, ship manufacturing, sheet metal cutting, kitchenware, cooling and ventilation pipes, sports industry, metal signs and other metal parts processing industry, sports industry.

Warranty and Service for 3D Robotic Fiber Laser Cutting Machine for Metal



1. 2 years warranty for the fiber laser source and other parts without consumable parts.

2. Life-long maintenance.

3. Except the damage artificially, we are responsible for offering the fittings free of charge during the warranty period.

4. After the warranty period expired, the buyer only need to pay the actual maintenance cost.

5. Manuals and CD along with machine, 24/7 one-to-one free service and support with Whatsapp, Skype, Email, Phone or Online Live Chat. It is available for door-to-door training and installation.



International Shipping Around the World



All the CNC laser machines can be shipped worldwide by sea, by air or by international express logistics via DHL, FEDEX, UPS. You are welcome to get a free quotation by filling up the form with name, email, detailed address, product and requirements, we will shortly contact you with the full information including the most suitable delivery method (fast, secure, discreet) and freight.
