Special Design for China Advertising CNC Router 6090 Wood / Acrylic / Metal / Plastic CNC Cutter Router with Ce Certificate

Short Description:

* Furniture: wooden doors, cabinets, plate, office and wood furniture, tables, chair, doors and windows.
* The wood products: voice box, game cabinets, computer tables, sewing machines table, instruments.
* Plate processing: insulation part, plastic chemical components, PCB, inner body of car, bowling tracks, stairs, anti-Bate board, epoxy resin, ABS, PP, PE and other carbon mixed compounds.
* Decorate industry: Acrylic, PVC,MDF, artificial stone, organic glass, plastic and soft metals such as copper, aluminum plate engraving and milling process.


Product Detail

video

Product Tags

Our goods are commonly recognized and reliable by consumers and may satisfy continually developing economic and social needs for Special Design for China Advertising CNC Router 6090 Wood / Acrylic / Metal / Plastic CNC Cutter Router with Ce Certificate, The main goal of our company would be to live a satisfactory memory to all of the shoppers, and establish a long term company romantic relationship with customers and users all around the entire world.
Our goods are commonly recognized and reliable by consumers and may satisfy continually developing economic and social needs for China CNC Router 6090, CNC Cutter Router, We firmly think that we have the full capability to present you contented merchandise. Wish to collect concerns within you and build a new long-term synergy romantic relationship. We all significantly promise:Csame excellent, better selling price; exact selling price, better quality.

Mini 6090 CNC router kit with 24×36 inches table size is widely used in small shop, small business, home shop, home business and craftsman for wood, plastic, MDF, PVC, PCB, acrylic, crystal, soft metal materials, etc. Now the best 2×3 CNC router 6090 for sale at cost price.

Demonstration Video

Product Descriptions

CNC Router 6090

Advertising Cutting engraving mini CNC FM6090T

1. Advantage of Machine
1) Water cooling spindle, with high precision, long life time, steady working, easy to start up.
2) Taiwan Hiwin linear square guide rail, self-lubricating sliding block. It ensures equal
force in all directions and accuracy and strength of the machine.
3) Taiwan TBI ball Screw transmit, ensured high accuracy and stable when working.
4) Stepper motors and Drivers, 3 sets in total, with big torque, ensure machine stable
5) DSP controller system with USB interface,working without connecting with computer
during working and easy to control.

2. Descriptions of Machine:

Description Parameter
X,Y,Z Working Area 600mmx900mmx80mm
Table Size 750mm×1050mm
Table Surface T-slot Table
Spindle Power 1.5KW water cooling spindle
Spindle Speed 0-24000RPM
Motors Stepper motors
Driver Leadshine or YAKO driver
Transmission X,Y,Z Axis: Taiwan TBI ball Screw
Machine Guide Rails Taiwan Hiwin Linear square guide rail
Inverter Fuling or Delta Inverter
Operating System DSP control system
Soft Limit switch Japan Omron limit
AC contactor France Schneider
X,Y,Z Traveling Positioning Accuracy ±0.03/300mm
X,Y,Z Repositioning Accuracy ±0.02mm
Max. Rapid Travel Rate 12000mm/min
Max. Working Speed 8000mm/min
Max. Power Consumption 3KW(Without Spindle)
Working Voltage AC220V/60Hz
Command Language G Code
Computer Interface USB
Flash Memory 128M(U Disk)
Collet ER20
Software Compatibility Artcam OR Type3 Software
Running Environment Temperature 0 - 45 Centigrade
Relative Humidity 30% - 75%
Packing Size 1710 X 1250 X 1585mm
N.W. 150KG
G.W. 200KG
Optional Parts Spindle: Air cooling spindle can be choose
Control system:  NC Studio/Syntec/mach3
Dust Collector
Rotary System
Mist-cooling System

3. Applicable materials of Machine

Materials Cut Engrave
Acrylic/Plexiglas/Perspex Yes Yes
Organic board/Matte board/Double color plate Yes Yes
Wood/Bamboo/Veneer/MDF Yes Yes
Leather/Pig leather/Cow Leather/Sheep leather Yes Yes
Fabric/Cloth/Textile Yes Yes
Wool Felt Yes Yes
Paper/Cardboard/Chipboard press board Yes Yes
Plastic ABS/PVC/rubber/plastic Yes Yes
Ceramic/Tile/Marble/Stone/Granite/Tombstone No Yes
Fiber glass crystal/Glass No Yes
Others non-metal materials Yes

广告机样品组图 (2) 广告机样品组图 (3)
Cutting Engraving Mini CNC FM6090 Advertising Engraving CNC Router

4. How to Order Our Machine?
Before we can recommend you the best suitable machine, please kindly tell us:
1)  What materials will you work on?
2)  What is your Max.size of your processing materials? ( Length & Width )
3)  Do you mainly engrave or cut? If cut,What is your Max.cutting thickness?
4)  Does your materials are cylinder? If YES, what’s the Max. Diameter of it?
5)  If it is possible, could you send us your product samples’ picture? It will help us better to
understand.

5. Trade Items of Machine

MOQ 1 set
Package Standard Plywood Box
Delivery Terms FOB, CIF, EXW, Door to Door ect.
Delivery Time 15 working days after receiving payment
Payment Type T/T, Paypal, Western Union and others
Supply Ability 200 sets/month
Port Qingdao, China.

Our goods are commonly recognized and reliable by consumers and may satisfy continually developing economic and social needs for Special Design for China Advertising CNC Router 6090 Wood / Acrylic / Metal / Plastic CNC Cutter Router with Ce Certificate, The main goal of our company would be to live a satisfactory memory to all of the shoppers, and establish a long term company romantic relationship with customers and users all around the entire world.
Special Design for China CNC Router 6090, CNC Cutter Router, We firmly think that we have the full capability to present you contented merchandise. Wish to collect concerns within you and build a new long-term synergy romantic relationship. We all significantly promise:Csame excellent, better selling price; exact selling price, better quality.
