Linear Atc CNC Router for Wood Door Carving Furniture Making Machine with a Saw Cut

Short Description:

1, High productivity. ATC CNC router can meet the tool changing requirements during processing without manual participation. With simple and easy operation mode to learn, which can help users quickly grasp the use of methods and greatly improve production efficiency.


2, Good software compatibility. Adopting open software interface, it can be compatible with the processing codes generated by various CAD / CAM design software, such as type3 / Artcam / Castmate / Wentai, to ensure the realization of various design functions.


Product Detail

Product Tags

Product Description:

1. High-quality HQD 9.0 kw of air-cooled spindles, ensures efficient operation.2. 850W servo motor high-power drives.3. New desigan machine with a saw for fast cut4. Vacuum table with T-slot (Clamps) table, more convenient for woodworking.5. Heavy Reliable steel frame, six lag more stable.6. The Automatically lubrication system ensures the stability of mechanical parts.7. 8-12 Tool Magazine, Tool changer automatically, many times increases productivity.8. Taiwan’s SYNTEC control system is more convenient to operate the machine for processing 2D, 3D engraving.

9. Hiwin 25 square guide rails and rack transmission

10. Breakpoint memory, can continue to work after power off & breaking cutter tools

8a433caba651ec49acbf912e8ca54be

Technical Date:

Model APEX1325 APEX1530 APEX2030
Working area 1300*2500mm 1500*3000mm 2000*3000mm
Z feeding 300mm
Frame structure Steel casting-welding
Type of table cover Vacuum table with T-slot
Vacuum pump 5.5kW/7.5kw air cooling
Z axis transmission Ball screw and 25 square guide rails
X Y axis transmission TBI / Hiwin 25 square guide rails + rack
Max. Rapid Travel Rate 33000mm/min
Max. Working Speed 25000mm/min
Command Code G code * .u00 * .mmg * .plt
Operating voltage AC 380V/50Hz
Spindle power 9.0 KW
Tool Magazine 8 – 12
Type of cooling Air cooling
Saw Adjustment freely on X and Y
Spindle Speeds 0-24000rpm/min
Drive motor type Servo
operating system Taiwan SYNTEC
Dust Collector With
Lubrication system With
Sensor for positioning the cutter With
Supported software Artcam software, Type3 software
Operating conditions Humidity: 30% -75%, temperature: 15 – 45 degree
Warranty One year

样品图 (2) 样品图 (6) 样品图 (7)
