2021 Best CNC Stone Carving Machine for Sale OEM service available
2021 best CNC stone carving machine STS1530 is the best choice for the owner in stone processing industry, decoration industry, sign making industry and woodworking industry etc. Now the best CNC stone carving machine for sale at affordable price.
Product Descriptions
2021 Best CNC stone carving machine Applications:
Stone Industry: Stone, ink-stone cutting, tomb stone, jade and marble products.
Kitchen Ware Industry: Man-made marble cabinet table surface.
Artwork Decoration Industry: Wood crafts, gift box, jewelry box and other exquisite art crafts.
Woodworking industry: Chair, door, window, bed, cabinet, kitchen ware and other furniture; Redwood classical and antique furniture, Exquisite European furniture, decorative products sculpture.
Mold Industry: Engraving copper, aluminum, and other metal molds;Building models, shoes, badge, embossed mould, biscuit, candy, chocolate mould; Artificial marble, plastic sheeting, PVC, wood, foam and other non-metallic mold.
Advertising Industry: Billboard, signage, badges, logo, company plate, signs, emblem, badge, display panels, fair signs, building numbers, signs of decoration, literal hole cutting etc.; 3D character cutting, acrylic cutting, LED/neon channel, lightbox;
Technical Parameters of CNC stone carving machine:
| Description | Parameter |
| X,Y,Z Working Area | 1300mmx2500mmx300mm |
| Table Size | 1450mm×2940mm |
| Table Surface | T-slot Table |
| Frame | Thicker Welded Steel tube Structure |
| Spindle Power | 5.5KW water cooling spindle |
| Spindle Speed | 0-24000RPM |
| Motors | 450B stepper motors ( 4 sets in total ) |
| Driver | Leadshine driver |
| Transmission | X,Y Axis: Helical Rack and Pinion Drive Z Axis: Taiwan TBI ball Screw |
| Machine Guide Rails | Taiwan Hiwin Linear square guide rail |
| Inverter | Fuling Inverter |
| Operating System | N105 DSP control system |
| Soft Limit switch | Japan Omron limit |
| AC contactor | France Schneider |
| X,Y,Z Traveling Positioning Accuracy | ±0.03/300mm |
| X,Y,Z Repositioning Accuracy | ±0.03mm |
| Max. Rapid Travel Rate | 33000mm/min |
| Max. Working Speed | 25000mm/min |
| Max. Power Consumption | 7KW(Without Spindle) |
| Working Voltage | AC380V/50Hz, 3Phs (Option: 220V) |
| Command Language | G Code |
| Computer Interface | USB |
| Collet | ER25 |
| Software Compatibility | Artcam OR Type3 Software |
| Running Environment Temperature | 0 - 45 Centigrade |
| Relative Humidity | 30% - 75% |
| Packing Size | 3300mm*2100mm*2300mm |
| N.W. | 1450KG |
| G.W. | 1680KG |
| Optional Parts | Motor and Driver: Servo system Japan: Yaskawa / Panasonic servo China: Taiwan Delta servo |
| Control system: NC Studio/Syntec/mach3 |
Features:
1) Spindle: China best brand CS 5.5kw water cooling spindle , which guarantees the high working speed, accuracy, rotating precision.2) Inverter: Fuling Inverter or Delta Inverter is optianal, it guarantees the high working speed and accuracy, and engraves without any ripple, but with smooth bottom level and clear outline.
3) Motor: Servo motor and stepper motor is optional, which guarantees the positional accuracy.
4) Driver: For stepper motor, Leadshine bigger driver; For servo motor, use matching driver. It can supply a steady stream power for motor.
5) Guide Rail:Taiwan Hiwin linear rail, self-lubricating sliding block. It ensures equal force in all directions and accuracy and strength of the machine.
6) Screw Transmission:Taiwan HIWIN screw transmission, it has high efficiency,sensitivity, positioning accuracy, long life.
7) Rack: Using Helical rack and pinion transmission, it has higher accuracy.
8) Control system: Use NK105 DSP controller, with stable and easy operation. ( NC Studio, mach3 can be choosed)
9) France Schneider contactor and leakage protector, protect the machine circuit well during the working.
10) High soft cables, tens of thousands of bending without damage.
11) Lathe bed is of high quality by cast steel, after re-treatment, much stronger and more stable. Aluminum table +PVC+ sink.
12) Mist-cooling system, prevent stone chips radiance when processing.
